1-9
Chapter 1 BEFORE OPERATION
No. Name Function
[1] First folding plate Guide plate for deciding a paper folding position. First folding
is made using this plate.
[2] Fine adjustment knob Used when adjusting a paper folding position.
[3] Rough adjustment knob Used when deciding a paper folding position.
[4] Control panel Used when operating the machine. Error messages are also
displayed on the LCD display.
[5] Second folding plate Guide plate for deciding a paper folding position. Second fold-
ing is made using this plate. This plate is not used when fold-
ing paper into two.
[6] Power switch Turns on and off the power.
[7] Paper set lever When lowered, the paper feed table is raised.
[8] Paper receiving tray Receives folded paper ejected out.
[9] Paper receiving stopper Stops paper ejected out from the machine.
[10] Table of stacker rollers position
(only for North America)
Used to check an appropriate position of the stacker rollers de-
pending on a paper size and folding pattern.
[11] Stacker rollers Ejects folded paper from the machine.
[12] Support paper feed plate Supports paper stacked on the paper feed table.
[13] Side guide Holds paper stacked on the paper feed table.
[14] Paper feed table Used to stack paper to be folded.
[15] Top cover Prevents the user from touching the moving parts.
[16] Paper feed ring Feeds paper into the machine.
[17] Rubber roll Sends paper to the rst folding plate.
[18] Paper feed pressure adjustment
knob
Adjusts paper feed pressure.
[19] Slant correction paper feed knob Corrects misalignment along sides of paper.
To Next Page
