4-5
Chapter 4 TROUBLESHOOTING GUIDE
Bearing support lever
Rubber roll
Paper
Bearing support lever
Non-operator’s side
Operator’s side
2
Turn the two bearing support levers
in the direction of the arrow to re-
lease them.
3
Pull the coiled paper towards you to
remove it.
If you cannot remove the paper easily, turn
the roll backward with both hands and pull
the paper.
4
Return the bearing support levers.
To Next Page
