11
5. NAMES AND OPERATION OF PARTS
5-1. External Parts
Guide plate for deciding the paper folding position
Safety cover to prevent the user from touching the moving parts
For operating the unit
For adjusting the paper feed pressure
For stacking the paper to be folded
For ensuring paper are stacked on the paper feed tray properly
For raising and lowering the paper feed tray when stacking paper
For turning on/off the power
For connecting external power
For securing folding plate 1
For controlling folding plate 1
For inserting control cord 1
Section which ejects folded paper from the unit
For aligning ejected paper
For receiving folded paper ejected out
Name
Operation
q
w
e
r
t
y
u
i
o
!0
!1
!2
!3
!4
!5
Folding plate 1
Top cover
Control panel
Paper feed pressure
adjusting lever
Paper feed tray
Auxiliary paper feed
tray
Paper set lever
Power switch
Power inlet
Folding plate 1 lock
lever
Control cord 1
No.1 connector
Paper ejection section
Paper receiving stopper
Paper receiving tray
No.
<Paper feed side>
<Paper ejection side>
11
12
13
15
14
1
2
3
4
10
5
6
9
7
8
