17
6. CONTROL PANEL
(2) 4-digit right window
No. of processed sheets counted by the add-count method. Maximum count displayed is
9999.
Paper length entered in the standard folding of non-standard paper (unit: inch).
Corrected value of the folding stopper position (folding position) in standard folding (unit: inch).
When “.030” is displayed, it means that the folding stopper of folding plate 1 or 2 is set 0.03"
from the automatically set position in direction A shown in the figure on page 15.
When “–.040” is displayed, it means that the folding stopper of folding plate 1 or 2 is set 0.04"
from the automatically set position in direction B shown in the figure on page 15.
Value set for the folding stopper position (folding position) in custom folding (unit: inch).
When “8.97” is displayed, it means that the length of the folded plane (see figure below) by
folding plate 1 or 2 will be about 8.97".
The value displayed is an approximate, and the actual folded size may differ according
to the thickness and characteristics of the paper used.
NoteNote
Length of
folded plane
Position of the stacker roller set. Can be set within the range of roL. 1 to 6.
The right window also shows error messages for paper jamming, etc. For details, refer to “18. ERROR
MESSAGES” (
☞
p.52).
NoteNote
To Next Page
