Chapter 1 Before Operation
Copyright © 2019 Duplo Corporation All Rights Reserved
9
10
9
Open the top cover.
Open or close the top cover
gently.
Hands or ngers may be caught in the
cover section. Doing so may result in
injury.
10
Rotate the jam correction handle to check that the folding roller rotates smoothly.
11
Place the cross fold lever as shown in
the figure.
Be sure to store the cross fold lever at
the specified place and in the specified
direction. By moving during operation
of this machine the folding roller may be
damaged, resulting in malfunction.
12
Close the top cover.
13
Open the paper receiving tray to the
right side seen on the operator’s side.
14
Attach the auxiliary paper ejection
guide to the stacker roller.
To Next Page
