Duplo DF-990A - Deformed folding; Standard Folding of Non-Standard Paper

46
Chapter3AdvancedOperation
Copyright © 2019 Duplo Corporation All Rights Reserved
1-3. Deformed folding
The paper may not be folded properly due to the characteristics of paper. In such cases, check the following
points.
• Donotusepaperoutsidethespecications.
Particularly, deformed folding occurs
frequently in the use of thin, imsy paper not
appropriate.
• Lowertheprocessingspeedwhendeformed
folding occurs for thin and imsy paper.
“8-2. Thin paper mode” (p.61)
• Separatepaperwellpriortostacking.
Chapter 1 “8-1. Paper used” (p.30)
• Stackpaperonthepaperfeedtrayafteraligningwell,andsetthepaperfeedguidesatthecorrect
positions.Alsotightenthexingscrewsofthepaperfeedguidesrmly.
Chapter 2 “2-2. Stacking paper” (p.34)
2. Standard Folding of Non-Standard Paper
Standardfoldingofnon-standardpaperisamethodtoperformpaperfoldingbysavingpaperlengthsother
than standard paper and selecting the folding mode of standard folding.
Paperotherthanthesixstandardpaperiscallednon-standardpaper.(TheA6,A7,orB7papercanbeused
asnon-standardpaper.)(vestandardpapersizesForNA)
Thefoldablesizesareasfollows.(widthxlength)
Length : 105.0 to 457.2 mm/
4.13 to 18.00 inches
Width :
74 to 311 mm/
2.91 to 12.24 inches
Paper feed
direction
Paper
Maximum :311x457.2mm/12.24x18.00inches
Minimum :74x105.0mm/2.91x4.13inches
Depending on the paper length, the following
folding modes are limited.
Doublefold,irregularaccordionfold-out:
182.0to457.2mm/7.17to18.00inches
Letterfold,Accordion-fold:
141.0to457.2mm/5.55to18.00inches
Gate fold:
128.0to432.0mm/5.04to17.00inches
• Standard paper which is stacked on the paper feed tray in the long edge feeding direction is
considered non-standard paper.
• The paper sizes which can be used may vary with the paper type, thickness, and printing
state.
Example:Whenperformingletterfoldon300.0mmlengthpaper
1
Touch the key on the [Ready] screen —> Touch [Standard Fold for Non-Standard
Size].
2
Using the numeric keypad, enter the paper length [300] —> Touch the key.
