Duplo DocuCutter CC-228 Service And Parts Manual

-
14
-
2.8 Front Lower Trasport Roller Asm (Fig. 7)
NO Index P/N Name Q’TY
1
2.8.01
881-H01-000A
Roller, Transport, CC-228 1
2
2.8.02
00G-M10-1910
Gear, M1, 19T, ID10 1
3
2.8.03
00B-F19-80ZZ
Ball Bearing, LF-1980ZZ 2
4
2.8.04
00C-016-080A
Collar, OD16, ID8
1
5
2.8.05
08P-51G-0800
Pulley, 0.8 P,51G,ID8 2
Fig. 7
