Duplo DocuCutter CC-228 Service And Parts Manual

-
22
-
2.15 Slitter Asm (Fig. 14)
NO
Index P/N Name Q’TY
1
2.15.01
881-801-000A
Chassis, Slitter, 2 x 3.5” 1
881-801-010A
Chassis, Slitter, 5.47X 4.21” 1
2
2.15.02
881-803-000A
Side Plate, L, Slitter 1
881-802-000A
Side Plate, R, Slitter 1
3 2.15.03 881-805-000A Shaft, Slitter, Lower 1
4
2.15.04
881-804-010A
Shaft, Slitter, Upper, 2x3.5” Slitter 1
881-804-020A
Shaft, Slitter, Upper, 5.47x4.21” Slitter 1
5
2.15.05
881-807-000A
Slitting Wheel, Center Gutter, 0.5” 1
881-807-010A Slitting Wheel, Center Gutter, 6mm 1
881-807-020A
Slitting Wheel, Center Gutter, 0.25” 1
881-807-030A
Slitting Wheel, Center Gutter, 3mm
6
2.15.06
881-808-000A
Slitting Wheel, Side Trim 2
7 2.15.07 881-827-000A O Ring, JASO 2027 3
PU
8 2.15.08 881-810-000A
Roller, Ejection Driving, Slitting Module 2
POM
9 2.15.09 881-115-0000
Belt, Transport, Slitting Module 2
PU
10 2.15.10 881-809-020A
Roller, Transport, Slitting Module 4
11 2.15.11 881-806-000A Slitting Wheel, Upper, CC-228 4
12 2.15.12 00B-F69-01ZZ
Ball Bearing, F6901ZZ 4
13 2.15.13 00E-M10-E000
E-Ring, 10mm 2
14 2.15.14 00G-M10-3112
Gear, M1.0, 31T, ID12 2
15 2.15.15 881-812-000A Deflector, Side Waste, 0.5” 2
881-812-000A
Deflector, Center Gutter, 0.5” 1
881-812-010A
Deflector, Center Gutter, 0.25” 1
881-812-020A
Deflector, Center Gutter, 6mm 1
881-812-030A Deflector, Center Gutter, 3mm 1
16 2.15.16 881-114-0000
Asm, Upper Ejection Roller 2
2.15.16.01
881-114-010A
Roller, Upper, Ejection 2
POM
2.15.16.02
881-114-020A
Spring, Upper Ejection Roller 2
2.15.16.03
881-114-030A Pin, Upper Ejection Roller 2
2.15.16.04
00E-M03-E000
E-Ring, M3 4
17 2.15.17.01
881-113-000A
Roller, Lower, Ejection 2
POM
2.15.17.02
881-113-010A
Pin, Lower Ejection Roller 2
2.15.17.03
00E-M03-E000
E-Ring, M3 4
18 2.15.18 881-R17-000A
Handle 1
