Duplo DocuCutter CC-228 Service And Parts Manual

-
20
-
2.14 Cutting Knife Asm (Fig. 13)
N
O
Index P/N Name Q’TY
1
2.14.01
881-711-000A
Chassis, Cutting Knife Mounting 1
2
2.14.02
881-705-000A
Knife, Lower, CC-228 1
3
2.14.03
881-714-000A
Asm, Middle, Upper Knife Holding Spring 1
2.14.03.1
881-714-010A
Spring, Middle, Upper Knife Holding Spring Asm 1
2.14.03.2 881-714-020A
Pin, Middle, Upper Knife Holding Spring Asm 1
2.14.03.3 881-714-030A
Bushing, Middle, Upper Knife Holding Spring Asm 1
2.14.03.4 00B-0L9-40ZZ
Ball Bearing, L940ZZ 2
4
2.14.04
881-717-000A
Nut, Middle, Upper Knife Holding Spring Asm 1
5
2.14.05
881-716-000A
Asm, Right, Upper Knife Holding Spring 1
2.14.05.01
881-716-010A
Spring, Right, Upper Knife Holding Spring Asm 1
2.14.05.02
881-716-020A
Pin, R/L, Upper Knife Holding Spring Asm 1
2.14.05.03
881-717-030A
Bushing, R/L, Upper Knife Holding Spring Asm 1
2.14.05.04
00B-0L9-40ZZ
Ball Bearing, L940ZZ 2
2.14.06
881-715-000A
Asm, Left, Upper Knife Holding Spring 1
2.14.06.01
881-715-010A
Spring, Left, Upper Knife Holding Spring Asm 1
2.14.06.02
881-716-020A
Pin, R/L, Upper Knife Holding Spring Asm 1
2.14.06.03
881-716-030A Bushing, R/L, Upper Knife Holding Spring Asm 1
2.14.06.04
00B-0L9-40ZZ
Ball Bearing, L940ZZ 2
6
2.14.07
881-718-000A
Nut, L/R Upper Knife Holding Spring Asm 2
7
2.14.08
00S-000-1515
Sensor, Mark Reader, White, EE-SB5 1
