9.4 Pinch Roller Pressure Setting
********To set pinch roller little bit tight***********
9.5 Separator Setting
While using the Weight to hold the feed pile, the Separator is not necessary to use,
If the weight still experiences double feed, please set the separator as below:
9.5.1 Think stock 200gsm~ 400gs
a. Rotate the knob clockwise to lower the separator down allow the paper strip in
b. Place a piece of 200gsm paper strip between suction belt and double feed stopper.
c. Rotate the knob counterclockwise to hold the sheet against the suction belt.
d. Pull the sheet to feel, it has a little bit drag and tight.
9.5.2 For 2 or 3mm thick stock, using the substrate to be fed as a gauge to set it loose.
