9.6 Setting the Clapper
9.6.1 Loosen the clapper holding Screw and push it aside.
9.6.2 Press to bring one sheet in to standby position
9.6.3 Move the clapper in and against the edge of the sheet. Be sure to eepk 0.5~1mm spacing.
9.7 Change Blower Speed
The blower force is adjustable, thin stock say 200gsm set it to SP-2~3, thicker substrates set it
to SP-4 by holding the then tip on to change the speed from
SP1>>SP2>>SP3>SP4>>SP1>>SP2>>SP3>>SP4 cycle.
9.8 Optimum the gap between sheets
There is 0~9 can be adjusted, each no represents 15mm increment.
Press the sheet will be fed and parked at standby sensor, hold + tip on ,
every tip has 1 increment, total 0~9 can be adjusted, each number represents 15mm
increment. 6 for B2+ or B2 sheet, 9 for 19x13” sheet.
9.9 Reset Counter
Hold the for 1 second, it will be rest to 0
