DURAG D-FL 200 - Page 31

D-FL 200 / Rev. 6 28
______________________________________________________________________________________________________
Industrie Elektronik GmbH & Co KG
R10 Measuring plane
1 Measuring plane
0001
2 Measuring planes
0002
corresponds with two
transducers (standard)
corresponds with four
transducers
R11
calculation mode
Calculation
mode
Calculation
0000
0001
0002
0003
0004
0005
0006
constant temperature,
constant absolute pressure
extern temperature input,
constant absolute pressure
constant temperature,
extern absolute pressure input
extern temperature input and
extern absolute pressure input
ultrasonic temperature calculation
and constant absolute pressure
ultrasonic temperature calculation
and extern absolute pressure input
ultrasonic temperature calculation
and constant absolute pressure, output of
the ultrasonic temperature on standard flow
output, measuring range 0-400°C (corr. 32-
752°F)
R12
zero_tmperature_in
Beginning of measuring range for temperature sensor (4
mA) (0-800°C) (corr. to 32-1472°F)
R13
Span_tmperature_i
n
End of measuring range for temperature sensor (20 mA) (0-
800°C) (corr. to 32-1472°F)
R14 Zero_pressure_in Beginning of measuring range for absolute pressure sensor
(4 mA) (0-1500hPa)
R15 Span_pressure_in End of measuring range for absolute pressure sensor (20
mA) (0-1500hPa)
R16 const_tmp constant temperature (0-800°C) (corr. to 32-1472°F)
R17 const_p constant absolute pressure (0-1500hPa),
default 1013
Parameter Code_2
Release code for internal parameterisation,
only for internal
use at Durag factory
,
code = 200
R22 Frequency Drive frequency for ultrasonic sensor / evaluation algorithm
(10-100kHz),
MK1=
50
kHz, MK2=
41
kHz, MK3=
30
kHz
