D-FL 200 standard
system MK3
Description Order no. Quantity
Consist of:
D-FL200 standard,
complete system
D-FL 200 SYS3 1
1 evaluation unit D-FL 200-10 1
2 sensor unit 50kHz D-FL 200-MK3** 2
3 welding flange D-FL 200-MF3** 2
4 signal cable, 15m / 49 ft BFL 200/Leitung 2
5 purge air unit "G" * incl.
10m / 33ft purge air hose
D-R 216 GN 1
6 PC-configuration program
fl200com.exe
D-FL 200-COM 1
7 serial PC-cable 1,5m (5ft) D-FL 200-PC 1
8 manual D-FL 200-BHB 1
9 customer specific calculations D-FL 200-AuB 1
* For ducts with gas temperature above dew point
** The length number of the flange and the measuring head must be added according to the figures in
section
15. Technical Data
, page
38
.
Optional accessories
Description Order no. Quantity
1 temperature transmitter D-FL100-TM/H 1
2 pressure transmitter D-FL100-ADM/H 1
3 purge air unit "E" *** incl.
10m /33ft purge air hose
D-FL 200-GN 1
4 acid resistant purge air hose wdisäureschlauch 10m
5 gas flow protection screen D-FL 200-SB 1
6 purge air supervisor system D-SK 300-10
7 simple purge air watchdog with
pressure switch at the fan
D-SK 200-DSCH 1
8 blind flange with sealing ring D-FL 200-BF 1
9 weather protective hood for the
sensor unit
D-WSH 200-MK 1
10 weather protective hood for the
evaluation unit
D-WSH 200 A 1
11 weather protective hood
for purge air unit "G"
D-WSH 290 GN 1
12 weather protective hood
for purge air unit "E"
D-WSH 280 GN 1
*** For ducts with gas temperature below dew point
