6.9 Lifting the sewing foot
Subclass -170010; -180010
The sewing foot can be raised mechanically by operating the knee
lever 1.
Subclass -170115; -180115
The sewing foot can be raised electro-pneumatically by operating the
foot pedal 2 or the knee lever 1.
Raising the sew ing foot mechanically (knee lever)
–
To adjust the position of the material (e.g. for corrective purposes),
push the knee lever 1 to the right or press the pedal 2 half-way
back.
The sewing foot stays in the up position as long as pressure is
maintained on the knee lever 1.
Raising the sew ing foot electro-pneumatically (pedal)
–
Press the pedal 2 half-way back.
The sewing feet are raised with the machine at a halt.
–
Press the pedal 2 all the way back.
The thread is severed and the sewing foot raised.
17
1
2
