- 45 -
DXE-GUY-Kits - Guying Kits for Vertical Antennas
Some vertical manufacturers indicate their antennas do not need guying. During times of high winds or ice loading,
some of these verticals may sustain damage or fail altogether. With the small amount of effort needed to install a four
point guying system, the risk hardly seems worth taking. A four-point guying scheme provides the best mechanical
advantage to reduce wind stress, regardless of direction. A four point guying system is recommended for use with a DX
Engineering Tilt Base, because just one of the guy ropes has to be loosened when you tilt the vertical down. The
remaining guys help stabilize the vertical in three directions when being raised. The guying kits are ideal for fixed or
portable installations.
4 - Heavy Duty screw-in earth anchors with eyelets
1 - 100 ft. Roll - UV resistant, 3/32 Double-Braided Dacron Polyester Rope SYN-DBR-94-100
4 - Heavy Duty screw-in earth anchors with eyelets
2 - 100 ft. Rolls - UV resistant, 3/32 Double-Braided Dacron Polyester Rope SYN-DBR-94-100
4 - Heavy Duty screw-in earth anchors with eyelets
4 - 100 ft. Rolls - UV resistant, 3/32 Double-Braided Dacron Polyester Rope SYN-DBR-94-100
4 - Heavy Duty screw-in earth anchors with eyelets
1 - 1000 ft. Roll - UV resistant, 3/32 Double-Braided Dacron Polyester Rope SYN-DBR-94-1000
DXE-MBV-ATU-1 - Multiband 43 ft Vertical Antenna Tuner Add-on Kit
The DXE-MBV-ATU-1 is the perfect solution for the modest power (200 watts maximum) DX’er who wants maximum performance
on a 43 foot tall multi-band vertical antenna! Now you can hear and work the weak ones! Just install on your antenna mount and
start operating. NO MANUAL TUNING! Now you can have full performance 80-10 meters with no coaxial cable mismatch
loss! A no compromise system! A Bias Tee is included with this special package for supplying the 12 Vdc power through the
coaxial cable from your radio shack to the remote tuner. Works on all DX Engineering, Zero-Five, MFJ and Hy-Gain 43 foot
vertical multi-band antennas. Also on your own vertical antenna homebrew creation! Shown here in a typical installation
with optional Radial Plate and Tilt Base.
DXE-MBV-ATU-1 Features:
• MFJ-927 Remote IntelliTuner™ - 200 Watts
• DXE-FCC050-H05-A Feedline Current Choke
• DXE-SSVC-2P Stainless Steel Mounting V-Clamp
• Custom Laser Cut Stainless Steel Bracket for Tuner and FCC
• Bias Tee Power Injector for 12 Vdc
• RG-8X 2 ft. Coaxial Cable with PL-259 Connectors
• 2 Tinned Copper Braids, 1" wide for connection to your optional Radial Plate
• Feedline wire - 14 ga. insulated stranded copper with Ring Terminal attached.
DXE-PSW-12D1A - AC Adapter 12VDC/1000mA
The DXE-PSW-12D1A is an AC Wall Transformer Adapter to furnish +12 Volts DC at 1000 mA from 110 Vac
60 Hz input, fused output. It features a standard 2.1 mm plug connection for +12 Vdc. Outer connection is
GROUND Center Pin is input for +12 VDC.
DXE-RADW - 500K or 1000K Radial Wire Kits and Components
To achieve optimal performance with a ground-mounted vertical, install as many radials as possible. These bulk radial wire kits
use insulated wire that is UV resistant, hard to see and lays down easily, unlike the wire that is commonly available at the big box
stores. It will last much longer in contact with soil than bare wire.
The DXE-RADW- 500K or 1000K kit provide everything you will need to build the perfect radial system!
500/1000 ft. spool of 14 AWG, stranded copper wire with vinyl insulation
20/40 lugs
100/200 radial wire anchor pins - Eliminating the need to bury your radials!
Build up to 20/40 radials, 25 feet long
Bulk Radial Wire Kit, 500 ft Spool of Wire, 20 Lugs, 100 Staples
Bulk Radial Wire Kit, 1000 ft Spool of Wire, 40 Lugs, 200 Staples
