47
Appendix A
Technical Specifications
This section gives the printer specifications for all the printers. You will also find information on
DYMO’s Software Development Kit which will allow you to use the LabelWriter printer and
software with your application.
LabelWriter Printer Specifications
300 330
330
Turbo
310 320 400 400 Turbo
Twin
Turbo
Duo
a
a. Label printer specifications
Print Method
Direct Thermal
Print Resolution
300 dots per inch (11.8 dots per mm)
Print Speed
(labels/min for address
label in text mode)
16 16 32 8 16 40 55 55 55
Maximum Print Width
1.57"
40 mm
2.25"
56 mm
2.25"
56 mm
1.57"
40 mm
2.25"
56 mm
2.25"
56 mm
2.25"
56 mm
2.25"
56 mm
2.25"
56 mm
Maximum Media Width
2.44" (62 mm) in all printers
Maximum Label Length
User-definable
Interface
USB (USB Spec 1.1 protocol);
Serial (Bi-directional, RS232) serial
USB (USB Spec
1.1 protocol)
USB 2.0 Full Speed Printer Class Device
Serial Printer Settings
115,200 baud, 8 data bits, no parity,
hardware handshaking
N/A N/A N/A N/A N/A N/A
Dimensions (WHD)
4 7/8" (12.4 cm) x 5 3/4" (14.6 cm) x 7 1/4" (18.4 cm)
(183 mm) x
(140 mm)
Weight
1 1/2 pounds (0.68 kg) (1.35 kg)
Average Print Head Life
2,000,000 linear inches (over 31 miles) 50800 linear meters
Printer Power
Requirements
100-240 V
~ 850 mA
47-63 Hz,
Class II
b
b. The LabelWriter printer’s internal power supply allows you to use it Worldwide with an appropriate adapter.
24 VDC 1.0 A 24 VDC 1.75 A
Rated Duty Cycle
(labels per hour)
1000 labels 1000 labels
per side
1000 labels
Regulatory Approvals
CE, FCC, cTUVus, GS and C-Tick
Warranty
Two Year Limited
