Dyna-Glo DGP480CSP - Grease Pan; Grease Cup

/3*DV*ULOO
$66(0%/<,16758&7,216

      
      
    

     
      
  

        
        
        
     
        
         
 



 




 
14
Step 12: Install the grease pan (19) and grease cup (20).
Put the grease pan (19) and grease cup (20) in position
as illustrated.
Step 13: Install 9V battery (26).
Place the 9V battery (26) into position in the battery box as
shown, then connect the battery box wiring and control knob
backlight wiring.
26
20
19
19
26
battery box and
control knob wiring
