20 CA 251 O251-1EN1
PARKING
11
The reserve brake knob (11) must always be pressed
if the operator has to leave his seat for any reason
while the engine is running. The brake warning lamp
(10) should then light.
Never leave the roller with the engine
running unless the parking brake knob is
pressed in.
The roller also has a parking brake that is automati-
cally applied when the engine stops or if hydraulic
pressure in the propulsion circuit fails.
Ensure that the roller is parked in a safe
place for traffic. Chock the drums if the
roller is parked on sloping ground.
Remember the risk of freezing during the
winter. Use anti-freezing agent in the engine
radiator and water tanks of the roller. See
also maintenance instructions.
Fig. 25 Left instrument panel
10. Brake warning lamp
11. Reserve brake knob
Fig. 23 Chocking the drum and wheels
1. Chock
Fig. 24 Battery box
1. Battery disconnecter
Turn off the battery disconnecter (1) and remove the
key before leaving the roller.
The battery disconnecter key should be
removed when the operator leaves the roller.
This will prevent discharging of the battery
and will also make it difficult for any
unauthorised person to start and drive the
machine.
1
10
1
