15CA 251 O251-1EN1
STARTING
Set the forward/reverse lever (24) in neutral. The
engine cannot be started if the lever is in any other
position.
Set the amplitude selector (27) to the 0 mode.
Press the button on the revs control (32) and increase
to ¼ throttle. Check that the starter switch (9) is at
position I.
Press the starter contact (8). Release the contact as
soon as the engine fires.
Do not run the starter motor too long. If the
engine does not start immediately, wait a
minute or so before making a new attempt.
Run the engine warm at about 1000 r/min for 5 to 10
minutes depending on the ambient temperature.
Check that the tachometer/hourmeter (19) gives a
reading. Check while warming up that the voltmeter
(13) indicates 13–14 volt, and that the oil pressure
warning lamp (12) is out. Check that the engine
temperature gauge (16) gives a reading towards the
end of the warming-up period.
Warning lamp (10).
When starting up and driving a cold roller
(cold hydraulic fluid) the braking distance
will be longer than normal until the machi-
ne reaches normal working temperature.
Ensure that ventilation (extraction) is
adequate if the engine is run indoors.
(Risk of carbon monoxide poisoning).
Fig. 13a Instrument panel
8. Starter contact
9. Starter switch
10. Warning lamp, brake
12. Warning lamp, oil pressure
13. Voltmeter
15. Temperature gauge, hydraulics
16. Temperature gauge, engine
19. Tachometer/hourmeter
32. Revs control
24
Fig. 13b Instrument panel
24. Forward/reverse lever
27. Amplitude selector
Starting the engine
15 16 19
13
12
10
32
9 8
27
