4 CC 222/222C - CC 232/232C - CC 322 M222EN5
Fluid volumes, litres (gal/qts) CC 222 / CC 222C CC 232 / CC 232C CC 322
Drum, l (qts) 13 13 13 13 16,5
Hydraulic reservoir, l (qts) 38 (40.2) 38 (40.2) 38 (40.2) 38 (40.2) 38 (40.2)
Fuel tank, l (gal) 120 (31.7) 120 (31.7) 120 (31.7) 120 (31.7) 120 (31.7)
Emulsion tank, l (gal) – 365 (96.4) – 365 (96.4) –
Water tank, l (gal) 365 (96.4) 365 (96.4) 365 (96.4) 365 (96.4) 365 (96.4)
Diesel engine, l (qts) 10,5 (10.6) 10,5 (10.6) 10,5 (10.6) 10,5 (10.6) 10,5 (10.6)
Electrical system
Battery 12 V 170 Ah
Alternator 12 V 80A
Fuses See the section entitled Electrical system, fuses
Compaction data CC 222 CC 222C CC 232 CC 232C CC 322
Static linear load, kg/cm (pli)
Front: 24,8 (138,9) 24,9 (139,4) 27,6 (154,6) 27,3 (152,9) 24,4 (136,6)
Rear: 25,5 (142,8) – 27,6 (154,6) – 25 (140)
Amplitude, mm (in)
High: 0,7 (0.028) 0,7 (0.028) 0,5 (0.020) 0,5 (0.020) 0,7 (0.028)
Low: 0,3 (0.012) 0,3 (0.012) 0,2 (0.008) 0,2 (0.008) 0,3 (0.012)
Frequency, Hz (vpm)
At high amplitude: 54 (3240) 54 (3240) 54 (3240) 54 (3240) 49 (2940)
At low amplitude: 70 (4200) 70 (4200) 70 (4200) 70 (4200) 49 (2940)
Centrifugal force, kN (lb)
At high amplitude: 89 (20,025) 89 (20,025) 89 (20,025) 89 (20,025)104 (23,400)
At low amplitude: 65 (14,625) 65 (14,625) 65 (14,625) 65 (14,625) 43 (9,675)
Propulsion CC 222 CC 222C CC 232 CC 232C CC 322
Speed range, km/h (mph) 0-13 (0-8) 0-11 (0-7) 0-13 (0-8) 0-11 (0-7) 0-13 (0-8)
Climbing capacity (theoretical) % 42 42 42 42 37
Tire CC 222C/CC 232C
Tire dimension 10,00 R20 Lisse
Tire pressure (kPa) 200 (29 psi)
TECHNICAL SPECIFICATIONS
Weights & dimensions CC 222 CC 222C CC 232 CC 232C CC 322
Service weight with ROPS, EN500 kg (lbs) 7700 7200 8400 7600 8700
(16,979) (15,876) (18,522) (16,758) (19,183)
Service weight without ROPS kg (lbs) 7300 6800 8000 7200 8300
(16,097) (14,994) (17,640) (15,435) (18,302)
Service weight with cab kg (lbs) 7750 7250 8450 7650 8750
(17,089) (15,986) (18,632) (16,868) (19,294)
Length, standard equipped roller, mm (in) 4300 4300 4300 4300 4300
(169) (169) (169) (169) (169)
Width, standard equipped roller, mm (in) 1575 1575 1575 1575 1810
(62) (62) (62) (62) (71)
Width, w. cab, mm (in) 1810 1810 1810 1810 1810
(71) (71) (71) (71) (71)
Height, w/o cab (Shipping height), mm (in) 2120 2120 2120 2120 2120
(83) (83) (83) (83) (83)
Height, w. cab, mm (in) 2920 2920 2920 2920 2920
(115) (115) (115) (115) (115)
Height, with AC (mm) 3230 3230 3230 3230 3230
(127) (127) (127) (127) (127)
Height, with AC and hazard beacon (mm) 3495 3495 3495 3495 3495
(137) (137) (137) (137) (137)
