6 CC 222/222C - CC 232/232C - CC 322 M222EN5
MAINTENANCE SCHEDULE
Fig. 1 Service and maintenance points
6
7
8
19
19 18 17 16 15 14 13 12 11 10 9
1 2 3 4 5
22
23
6
7
21
20
17. Hinges
18. Pivot cylinder
19. Rubber element
20. Drums, lubrication
21. Pivot bearing
22. Battery
23. Hydraulic fluid cooler
24. Tires (combo)
= CC 232/232C only
1. Air cleaner
2. Engine oil
3. Refueling
4. Seat bearing
5. Water tanks, filling
6. Watering system
7. Scrapers
8. Drums
9. Fuel tank
10. Steering joint
11. Steering cylinder
12. Hydraulic filter
13. Hydraulic fluid level
14. Hydraulic fluid, filling
15. Hydraulic reservoir
16. Diesel engine
24
523
8
