68 4812325556EN 2017-11-22
Check the tightness of the wheel nuts
Confirm the tightening torque of the wheel nuts (1) with 204 Nm
(47kpm).
Check all wheels and all nuts (this information is valid only for
new machines or newly installed wheels).
Check and clean the engine air filter elements
Replace the main filter element when the
corresponding warning light is illuminated on the
instrument panel when the engine is at full speed.
1. Loosen the clamps (1); remove cover (2) and the main filter
(3). Do not remove the safety filter (4).
2. Clean the air filter, if necessary, following the instructions on
this page.
3. When replacing the main filter (3), insert a new one in its
place and fit the air filter components in the reverse order.
4. Verify that the anti -dust valve (6) is in good condition and
replace if necessary.
5. When attaching the cover, make sure that the anti -dust
valve is facing down.
Replace the secondary air filter every five main air
filter uses.
To carry out the air filter cleaning, follow the instructions below:
1. Clean the inside of the cover and filter housing.
2. Also clean the surfaces of the outlet tube, as shown in the
picture.
Check that the hose clamps between the filter
housing and the intake hose are tight and that the
hoses are intact. Check all hoses system until the
engine.
Fig. – Air filter
1. Clamps
2. Cover
3. Main filter
4. Safety filter
5. Filter case
6. Dust valve
Fig.
Inside of the Outside of the
Outlet tube Outlet tube
