Scheduled maintenance
72 4812325556EN 2017-11-22
Replace the cab air filter
Use a step ladder to reach the filter (1). The filter
can also be accessed by the window at the right
side of the cab.
The filter is located at the front of the cab.
Remove three bolts and the protective plastic.
Remove the filters and replace them with new ones.
It may be necessary to replace them more frequently if the
machine is working in a dusty environment.
Check the alternator belt
With the machine stopped, check for cracks in the belt tensioner
arm.
Check the belt on the pulley location, it must be centered.
Inspect the belt daily, search for cracks, if any, replace it
immediately.
For more detailed information on inspection and
replacement belts refer to the engine manual.
Change the engine coolant
Caution! Risk of severe burns!
Wait until the engine temperature cools down to
122 F (50°C) before removing the coolant tank
cap or draining the coolant system.
1. Open the expansion tank cap.
NEVER open the coolant tank cap when the
engine is hot.
2. Drain the engine coolant system through the cooler valve
drain.
3. Use a proper container to collect the coolant (with 3.69 gal
or 14 liters of capacity).
Be careful when draining the product. Use gloves
and protective goggles.
Fig. Cab
1. Filters (2x)
2. Bolts (3x)
Fig. – Tensão da correia do alternador
Fig. –Alternator belt
Fig. - Drain plug
1. Drain plug
1
3
2
1
