DS322LR4-1 User Manual 10
Wall Mounting
• A wall mount is not included. Please purchase a VESA Standard wall mount to secure the LCD.
DynaScan is not responsible for damages caused by using non-standard wall mounts.
• Verify that the mounting location can support the weight of the LCD before installation.
• The installation angle must be within 15 degrees of the vertical axis.
• Do not install the wall mount while the power is turned on as it may cause serious injury from
electrical shock
Connecting to a Power Source
Using the power cable provided, plug it in the power inlet on the back of the display shown in the
diagram below. Connect the power cable to a 110-220 volt, 50 / 60Hz AC power outlet.
Insert the plug completely into the socket. A loose power connection may cause damage to the
display and/or lead to a fire hazard.
