DS322LR4-1 User Manual 12
Connector Positions
○
1
○
2
○
3
○
4
○
5
○
6
○
7
Power Switch
AC (IN) RS232 (IN) RS485 (IN) RS485 (OUT)
USB HDMI (IN)
○
8
○
9
DVI (IN) VGA (IN)
DS322LR4-1
○
6
○
7
○
8
○
5
○
4
○
3
○
2
○
1
○
9
