Dynaudio Sub 3 User Manual

34
Control possibilities
The Dynaudio Sub3 provides two
controls to match the frequency
response of the subwoofer and the main
speakers perfectly:
Note
Note: The settings for the cross-
over frequencies just have an
impact on the signal at the SAT/
SUB Input! The LFE channel
is just used to reproduce very
low frequent effect signals.
Consequently signals at the SUB
I/O - LFE/Slave In are not limited
in their frequency response.
SUB LowpassSAT Highpass
50Hz 150Hz
60HzFlat 80Hz
• SUB Lowpass: The upper cut-off
frequency of the subwoofer, which
can be continuously adjusted
between 50 and 150Hz. Above the
selected cut-off frequency the sound
pressure level decreases rapidly.
• SAT Highpass: The lower cut-off
frequency of the main speakers;
60Hz, 80Hz or Flat (neutral) can be
selected. Below the selected cut-off
frequency the sound pressure level
decreases rapidly.
B
ed

Dynaudio Sub 3 Specifications

General

On/off switch	Yes
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Subwoofer type	Active subwoofer
Number of subwoofers	1
Subwoofer peak power	300 W
Subwoofer driver diameter	240 mm
Subwoofer frequency range	22 - 175 Hz
Subwoofer crossover frequencies	60 - 80 Hz
Line inputs (RCA)	3

Weight and Dimensions

Subwoofer depth	320 mm
Subwoofer width	266 mm
Subwoofer height	276 mm
Subwoofer weight	10500 g
