Operation
Subwoofer inputs
The Dynaudio Sub3 provides two
different signal inputs:
SUB I/O - LFE/Slave In
This input allows the LFE (Low
Frequency Effect) channel to be
connected, which is used in home
cinema systems to reproduce low
frequency effects.
The signal is:
• reproduced by the subwoofer
• routed to the SUB I/O - LFE/
To Slave output for a second
subwoofer to be connected.
The SUB Lowpass control has no impact
on this input.
SAT/SUB Input
This input allows the connection of the
full bandwidth signal from the processor/
receiver (preamplier out).
The signal is:
• reproduced by the subwoofer,
• routed to the SAT Output terminals.
Low frequencies are cut-off
according to the SAT Highpass
setting,
• routed to the SUB I/O - LFE/
To Slave output for a second
subwoofer to be connected. High
frequencies are cut-off according to
the SUB Lowpass setting.
See gure above for correlations
between input, output and settings.
Connecting the subwoofer
t
he
e
ssor/
i
nals.
s
g
h
g
to

Dynaudio Sub 3 Specifications

General

On/off switch	Yes
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Subwoofer type	Active subwoofer
Number of subwoofers	1
Subwoofer peak power	300 W
Subwoofer driver diameter	240 mm
Subwoofer frequency range	22 - 175 Hz
Subwoofer crossover frequencies	60 - 80 Hz
Line inputs (RCA)	3

Weight and Dimensions

Subwoofer depth	320 mm
Subwoofer width	266 mm
Subwoofer height	276 mm
Subwoofer weight	10500 g
