Dynaudio Sub 3 User Manual

14
1. ON/OFF
Main power switch (to switch the
subwoofer manually on and off).
LED: shows operation mode:
• red = subwoofer switched on and
in mute mode
• green = subwoofer is activated
2. AC IN
Main power input.
3. POWER
Subwoofer auto power mode:
• ON = Auto mode disabled
(subwoofer is switched on
permanently, when main power
switch is set to ON).
• AUTO = Auto mode enabled (when
main power switch is set to ON
and a music signal is detected,
the internal amplier is activated
automatically).
4. GAIN
Subwoofer volume level.
5. PHASE
Phase setting: phase can be set to
0° or 180°.
6. SUB Lowpass
Subwoofer lowpass frequency:
continuously variable from 50 to
150Hz.
7. SAT Highpass
Allows cutting off low frequencies
of the signal provided at the SAT
Output:
• Flat = signal is not processed
• 60 = cut-off frequency at 60Hz
• 80 = cut-off frequency at 80Hz
8. SAT/SUB Input, SAT Output
• SAT/SUB Input: Input for full
bandwidth signal from processor/
receiver. This signal will be
processed according to the SAT
Highpass setting and provided at
the SAT Output connection for
satellite speakers to be connected.
• SAT Output: Output for satellite
speakers to be connected. This
signal is processed according to
the SAT Highpass setting.
9. SUB I/O, To Slave
• LFE/Slave IN: input for LFE signal
from processor/receiver. Note
that the signal must be a true LFE
signal or already have been ltered
by the processor/receiver, as SUB
Lowpass does not have an effect
in combination with the LFE input.
• OUT: output to next subwoofer if
installed.
10. LFE/Slave
Subwoofer operation mode LFE or
Slave:
• LFE: setting if just one subwoofer
is used or for rst subwoofer
if system consists of multiple
subwoofers. Note that the SUB
Lowpass control does not have
an effect when the LFE Mode is
selected.
• Slave: setting for second and all
following subwoofers. Note that
the SUB Lowpass, PHASE and
GAIN controls do not have an
effect when the Slave Mode is
selected.
Controls and connections
LFE
l
tered
SUB
effec
t
n
put
.
er i
f
E
or
o
ofer
U
B
a
v
e
is
d
all
h
at
a
n
d
n
is

Dynaudio Sub 3 Specifications

General

On/off switch	Yes
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Subwoofer type	Active subwoofer
Number of subwoofers	1
Subwoofer peak power	300 W
Subwoofer driver diameter	240 mm
Subwoofer frequency range	22 - 175 Hz
Subwoofer crossover frequencies	60 - 80 Hz
Line inputs (RCA)	3

Weight and Dimensions

Subwoofer depth	320 mm
Subwoofer width	266 mm
Subwoofer height	276 mm
Subwoofer weight	10500 g
