Dynaudio Sub 3 User Manual

35
Specic tips
General tips
SUB Lowpass = 80Hz
The cut-off frequency should be
selected as low as possible. Then
the subwoofer works without being
recognized as a single signal source.
Very often a cut-off frequency of
80Hz has been experienced as an
ideal value.
Reduce weak ampliers and
small speakers from bass load
By limiting the reproduction of low
frequency at the SAT Output,
ampliers and speakers connected
to this output are freed from
reproducing the heavy bass load,
which negatively impacts the sound
quality. This will improve the overall
sound of your audio system.
Play a music track that has a
signicant amount of bass over a
large bass region. An instrument
such as a double-bass or bass-guitar
is very suitable. Listen carefully
to the bass-line played by the
instrument. As it goes up and down
in the bass range, the overall bass
volume should remain the same –
be it with very deep or higher bass
notes.
General tips

Dynaudio Sub 3 Specifications

General

On/off switch	Yes
Product color	Black
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Subwoofer type	Active subwoofer
Number of subwoofers	1
Subwoofer peak power	300 W
Subwoofer driver diameter	240 mm
Subwoofer frequency range	22 - 175 Hz
Subwoofer crossover frequencies	60 - 80 Hz
Line inputs (RCA)	3

Weight and Dimensions

Subwoofer depth	320 mm
Subwoofer width	266 mm
Subwoofer height	276 mm
Subwoofer weight	10500 g
