12 Dynaudio
Connecting and setting up
Positioning and connecting to mains voltage
► Position the speaker in the desired location.
– Do not expose the speaker to direct sunlight, heat, or moisture.
– Do not place the speaker near devices with strong electromagnetic radiation or devices that
could be destroyed or damaged by magnetic elds.
► Use the power cable to connect the speaker to the mains voltage.
TIP:
For easier access, the plate at the bottom of the cabinet can be removed. Use a coin or
screwdriver to loosen the screw and attach the plate after connecting the power cable.
Cloth cover
The cloth cover has been designed so it does not inuence the sound dispersion of the speaker. It is
attached to the housing with magnets and may be removed if needed.
General settings
► In stereo mode:
– Select Left operating mode for the left speaker.
– Select Right operating mode for the right speaker.
► Set the speaker position switch that best describes the speakers´ need for acoustic compensation.
– Neutral = with free-standing placement
– Wall = if placed near a wall
– Corner = if placed in a corner
► Select the Red, Green, or Blue zone. Select the same zone for the right and left speakers (for
additional information about the audio zones see „Division into audio zones“ on page 23).
