Powerbox Pro series User Manual
22
Overcurrent and disconnection protection device must be installed between the battery and
the inverter that isolates both positive and negative conductors.
3) When the system used in parallel:
When the system is used in parallel, it supports up to 5 Powerbox Pro in parallel. According to
the number of parallel system (Take 5 Powerbox Pro in parallel as an example), it needs to use:
Power cable × 5 pair, Battery-Inverter communication cable × 1PCS, Battery-Battery
communication cable × 4PCS, Distribution box × 1PCS.The over-current capacity of the
distribution box should be much higher than the maximum nominal current value when the load
is running.
CAN communication
connection
To Next Page
