Dyon ENTER 40 - Rear Connection Board

EN
ENTER 40
12
3.3 Rear connection board

1. Video/ Y Connection
2. pb
3. Pr
4. Audio In Left
5. Audio In right
6. SPDIF
7. LNB In
8. Scart
1. USB
2. HDMI 2
3. HDMI 1
4. Headphone In
5. Common Interface (CI)
6. PC Audio IN
7. VGA
8. Antenna (75 Ohm)
4
5
6
7
8
1
2
3
1
2
3
4
5
6 7
8
