CI/CI+ Slot
This device is equipped with a CI+ slot for use with cam modules and smart
cards which allow for the viewing of encrypted Pay-TV channels.
The corresponding modules may be purchased from the Pay-TV provider or
specialized dealer.
Installation
1. Disconnect the TV set from power.
2. Before inserting the module into the device, insure that the smart card has
been properly installed into the module (). Pay close attention to the
direction when inserting.
The printing on the module and the chip of the smart card must be on top.
3. Insert the Module with inserted smart card with the printing of the module
facing backwards ().
Insert the module carefully into the slot of the device until a little resistance
is felt.
Using a little pressure, carefully press the module into the slot until it sits
firmly.
4. Reconnect the power source.
Remove the module
2. Disconnect the TV set from power.
3. To take the module out carefully.
