9 Connecting to PC
The unit can be connected to PC (personal computer) via the VGA cable.
Follow the figure below to connect:
1. Connect one end of the VGA cable to the VGA input jack on the rear panel
of the unit and connect the other end to the PC.
2. Connect one end of the audio cable to the PC audio input jack on the rear
panel of the unit and connect the other end to the PC audio output jack.
3. Power on the TV set and switch to PC mode (VGA) using the SOURCE
key.
4. Power on the PC.
5. Set the PC video resolution to match that of the television.
NOTE: It is very important to follow these steps exactly!
RESOLUCION V.Frec.(Hz) H.Frec.(KHz)
1 800*600 60 37.88
2 640*480 60 31.47
3 1024*768 60 48.36
4 1280*1024 60 63.98
5 1366*768 60 67.5
6 1920*1080 60 66.64
