Service manual
Fitting notes
19
40 Lower the upper chassis onto the
main body.
39 Ensure the cyclone inlet cable is
located into the channel provided
on the front of the main chassis.
38 If previously removed slide the
cyclone inlet onto the UMC.
Motorhead variant only
To Next Page
