Dyson DC 23 Service Manual

Fitting notes
Service manual
28
65 Fit the four screws in the motor
bucket.
66 Fit the six screws in the side of
the motor bucket.
67 Neatly dress the motor wiring
assembly under the clip and
within the channels on the end of
the motor bucket.

Dyson DC 23 Specifications

General

Model	DC23
Power	12 Amps
Type	Upright
Cyclone Technology	Root Cyclone Technology
Filtration	HEPA filter
