E Instruments 4400 - Replacing the particulate filter; Replacing the gas sensors

58
@IST01530EEJ 019175A0 190411
6.5 Replacing the particulate filter
If the particulate filter appears black, especially on the inner surface (see adjacent example), it has to be replaced
immediately. In this way gas flow is not obstructed.
6.6 Replacing the gas sensors
The gas sensors of the instrument shall be periodically replaced (see the following table) with new or recalibrated
sensors.
The user can easily perform this replacement operation according to the following instructions:
2
Extract the cover to have access to the sensor compartment.
1
Undo the two fixing screws on
the sensor compartment cover.
Blackened particulate filter
1
2
3
4
5
6
7
8
