2.0 TECHNICAL SPECIFICATIONS
2.1 Technical Specifications
Autozero: Automatic autozero cycle with probe inserted in the stack.
Dilution: Expansion system of the CO sensor measuring range up to 50,000ppm
(5.00%v/v) programmable as a simple protection of the CO sensor with triggering
threshold programmable by the user. Preset triggering threshold at 1,500 ppm.
Self-diagnosis: All the functions and internal functions are checked and anomalies signalled.
Type of Fuels/Oils: 7 predefined by the factory and 16 that can be programmed by the user.
Power: Li-Ion battery pack with internal protection circuit.
Battery charger: External battery charger.
Charging time: 2 hours for charging from 0% to 90% (3 hours for 100% charge).
Instrument working time: 16 hours of non-stop operation (excluding printing).
Printer: Internal, 24-column impact printer, using ordinary paper (roll 18 m long and
57 mm wide).
Printer powered: By the analyzer batteries.
Printer autonomy: Up to 40 analysis reports with the batteries fully charged.
Internal data memory: 300 complete data analyses, time and name of the customer can be stored.
User data: 3 programmable user names.
Print-out heading: 4 lines x 24 characters, customisable by the user.
Display: Graphic backlit LCD, measuring 42 x 60 mm.
Communication port: USB with mini-USB connector.
Line filter: With replaceable cartridge, 99% efficient with 20um particles.
Suction pump: 1.2 l/min heads at the flue up to 135hPa.
Condensate trap: Outside the instrument.
Carbon black: Using an optional external Smoke hand pump; it is possible to simply enter and
print the Smoke index results.
Leak test: Gas pipes tested for leaks with separate printout of the result, by means of the
attachment AACKT02, according to UNI 7129 (new systems) and UNI 11137-1
(existing systems), with automatic calculation of pipe volume.
Condensing boiler efficiency: Automatic recognition of the condensing boiler, with calculation and printout of
efficiency (>100%) on the LHV (Lower Heating Value) in accordance with
UNI10389-1.
Environmental gases: Measurement and separate printout of the ambient CO and NO values.
Draft test: Draft tested as per the UNI 10845 standard. Using the external draft gauge
AACDP02 the resolution is 0.1 Pa with 0.5 Pa accuracy.
Operating temperature range: -5°C to +45°C
Storage temperature range: -20°C to +50°C
Operating humidity range: 20% to 80% RH
Protection grade: IP42
Air pressure: Atmospheric
Outer dimensions: Analyzer: 30,7 x 10,5 x 9,6 cm (W x H x D)
Case: 48.2 x 37.5 x 16 cm (W x H x D)
Weight: Analyzer: ~ 1.1 kg
Compliant with the CEI-EN 50379-2 European Standard.
