Manually overriding the gearbox and removing the cover
Locked and engaged
Unlocked and engaged
Insert key and turn
clockwise.
Unlocked and
disengaged
Cover housing screw
beneath manual
override cam
Second cover screw
Fourth cover screw
Third cover screw
Remember to pull or push the gate gently until the gears “click” re-engage, before running the motor after a manual override.
When the override cam is in the manual override position the electronic control is disabled. To operate the control card the cam
must be in the engaged position.
