Page 12
OPERATION AND SERVICE INFORMATION
Owner’s Guide
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings.
B
.
Fig. 13 Headlight Bulb Replacement
3. Align the bulb with the opening in the back of the
headlight assembly.
4. Turn the bulb (3) counter clockwise until it stops.
5. Connect the accessory harness (5) to the light bulb
(3).
TURN SIGNAL BULB REPLACEMENT
Make sure that the vehicle key switch is in the ’OFF’ po-
sition and the key has been removed.
1. Remove the phillips head screw (7) and turn the
retaining collar (8) to align with the turn signal bulb
housing (9).
2. Grip the turn signal bulb housing (9) and pull back-
ward to remove housing from the headlight assembly.
Fig. 14 Turn Signal Bulb Replacement
3. Remove the bulb from the housing and replace with a
new one.
4. Push turn signal housing (9) into headlight assembly
firmly, making sure that it is seated completely.
5. Turn the retaining collar (8) to secure the bulb housing
and install the phillips head screw (7) to secure in
place.
TAILLIGHT/BRAKE LIGHT BULB REPLACE-
MENT
Make sure that the vehicle key switch is in the ’OFF’ po-
sition and the key has been removed.
1. Remove the two phillips head screws (10) that secure
the lens (11) to the taillight assembly.
2. Remove the light bulb.
3. Install the new light bulb.
4. Install the lens (11) and secure in place with the two
phillips head screws. (10)
Fig. 15 Tail and Brake Light Bulb Replacement
TRANSPORTING VEHICLE
TOWING
To reduce the possibility of severe injury or
death:
Use extra caution when towing a vehicle.
DO NOT ride on the vehicle being towed.
DO NOT attempt to tow the vehicle with
ropes, chains or any device other than a
factory approved tow bar.
DO NOT tow the vehicle on highways.
DO NOT tow a single vehicle at speeds in
excess of 12 mph (19 kph).
DO NOT tow more than three vehicles at a
time.
