EAE EE-6435B.WF - Technical Data; Nameplate

Installation, Operation and Parts Manual
EE-6435B .WF
14
3.5 Technical data
Item
Data
Power Form
Electro-hydraulic
Rated capacity of the lifting platform
4000KG(48L/52L), 5000KG(48L/52L/57L)
Full rise height of the main lift
1850mm
Initial height of the main lift
225mm
Full rise time of the main lift
≤70S
Full lowering time of the main lift
≤60S
Rated capacity of the secondary lift
4000kg
Rising height off the secondary lift
450mm
Initial height of the secondary lift
75mm
Full rise time of the secondary lift
≤25S
Full lowering time of the secondary lift
≤20S
Working pressure
Main lift ≥20MPa；secondary lift ≥24MPa
Electricity
AC 400 or 380V±5% 50Hz
Capacity
2.2kw
Hydraulic oil
12L, 46# hydraulic oil
Noise
< 75db
3.6 Nameplate
The nameplate is fixed beneath the oil tank
Check the work voltage and the lift capacity printed on the name plate.
Do not lift vehicles with weight beyond the capacity.
S/N and production date could be helpful for future service.
