Installation, Operation and Parts Manual
EE-6435B .WF
Lower the Secondary lift
Attention: in case the platform extensions of the auxiliary lift are used, the operator needs to release the extension
after the four wheels of vehicle lay on the main platforms.
1. Turn the optional switch on the control panel to “Secondary lift”.
2. Press “DOWN I” button on the control panel to lower the lifting platform of the secondary lift.
3. Take away rubber pads.
5.5 Emergency lowering in case of no power
In the case the safety lock is not engaged：
1. Push the front rod of the four electromagnets under the cross beam to have the four safety blocks released from the safety rods.
2. Press and screw loose counter-clockwise the unloading valve to lower the platform.
Safety block and safety rods
Front rod of electromagnet
