Installation, Operation and Parts Manual
EE-6435B .WF
17
4.1.4 Tools and equipment needed for installation
Tool name
Specification
Quantity needed
Electrical drill
With D16 and D18 drill bit.
1
Open spanner
D17-19mm
2
Adjustable spanner
bigger than D30mm
1
Cross socket screw driver
PH2
1
Quick spanner handle adapter/ Ratchet
1
Socket spanner
D24mm
1
Levelling device
1
Hammer
10 pounds
1
Truck lift
Capacity more than 2500KG
1
Lifting string
Capacity, 1000KG
2
Lifting string
Capacity, 2000KG
1
4.1.5 Checking parts
Unfold the package and check if any parts missed as per the following list. Do not hesitate to contact us in case any parts missed, but if you do
not contact us and insist installing upon the lack of some parts, we as well as our dealers will not bear any responsibility for this and will charge
for any parts subsequently demanded by the buyer.
S/N
Name
Qty
1
Power side post
1
2
Secondary post
3
3
Main crossbeam
1
4
Secondary crossbeam
1
5
Platform A
1
6
Platform B
1
7
Front wheel retainer
2
8
Post cap
4
9
Protective cover
4
10
Slider holder
8
11
Plastic chain
1
12
Wire terminal box
2
14
Rubber pad
4
15
Hex socket flat head screw M12*80
8
16
Hex socket button head screw M8*20
8
17
Hex head full swivel screw M12*30
4
18
Hex head full swivel screw M10*35
4
19
Spring washer Ф10
4
20
Hex nut M10
4
21
Flat washer Ф10
4
22
Anti-vibration pad
4
