4. Communication Setting (CS)
4.1 RS232 (rS232)
4.1.1 Baud Rate
When ENTER key is pressed from “rs232”, the display will show
‘9600’. Default value is 9600.
The following are the baud rates available -1200, 2400, 4800, 9600,
19200, 48000,115200.
Use the zero and tare keys to select between 1200 to 115200 as required.
Once the baud rate is selected, press ‘ENTER’ button to select,and after
selection the display will go to the previous menu and show the selected
baud rate.
Press Tare button to go to the next parameter.
4.1.2 Data Bits (db)
When ENTER key is pressed from “db 8”, the display will start
flashing ‘8’. Default value is 8.
The following are the data bits available-7 & 8.
Select as per requirement and press ‘ENTER’ button to select,and after
selection the display will go to the previous menu and show the selected
data bit.
Press Tare button to go to the next parameter.
