container.
2) Divide the spray gun. Press the hook (Fig. 5 "click") slightly downwards. Turn the gun
front part and gun rear part against each other and take them apart.
3)
Unscrew the container. Empty any remaining coating material back into the
material tin.
4)
Preclean the container and feed tube with a brush. Clean the ventilating bore (Fig.13,A).
5)
Pour solvent or water into the container. Screw the container back on.
Do not use ammable materials for cleaning purposes.
6) Assemble the gun again (Fig. 5).
7) Turn the device on and spray the solvent or water into a container or a cloth.
8)
Repeat the above procedure until the solvent or water emerging from the nozzle
is clear.
9) Turn the device o and unplug.
10) Divide the spray gun. Press the hook (Fig. 5 "click") slightly downwards. Turn the gun
front part and gun rear part against each other and take them apart.
17. Cleaning the Perfect Spray 800
spray attachment
1) Unscrew the container and empty it. Pull out the suction tub with container seal.
CAUTION! NEVER clean seals, diaphragm and nozzle or air holes of the spray gun with
metal objects.
The ventilation hose and diaphragm are only solvent-resistant to a limited
extent. Do not immerse in solvent, only wipe.
2) Pull the ventilating hose (Fig. 14, A) at the top from the gun body. Screw o the valve
cover (Fig. 14, B). Remove the diaphragm (Fig. 14, C). Clean all the parts carefully.
3) Unscrew the union nut and remove the air cap and nozzle. Clean the air cap, nozzle
seal and nozzle with a brush and solvent or water (Fig. 15).
4)
Clean the outside of the spray gun and container with a cloth soaked in solvent or
water.
5) Assemble the parts again (see “Assembly”).
