Earlex HV4901 - Accessories

EN
22
HV4901
Spare Parts List I-Spray attachment (Fig. 24)
Pos. Designation Order No.
Spray attachment complete with 1300 ml container 2352 129
1 Spray jet adjustment ring 2352 366
2 Union nut 2352 362
3 Air cap 2352 360
4 Nozzle 2328 908
5 Nozzle seal (2 pcs.) 2304 433
6 O-ring of spray attachment 0417 308
7 Ventilating hose, valve cover, diaphragm 2304 027
8 Suction tube 2328 922
9 Container seal 2328 919
10 Container with cover 1300 ml
(only for I-Spray attachment)
2305 155
Spare Parts List (Fig. 25)
Pos. Designation Order No.
1 Retainer clip (for Air hose) HV4901 2352 758
2 Hose Clip HV4901 2352 756
3 Air Hose HV4901 3m+adapter 2352 752
4 Air lter HV4901 2352 754
5 Gun handle 2303 300
6 Feed hopper (3 pcs.) 2304 028
* Parts are unavailable as replacements.
21. Accessories
The new CLICK&PAINT SYSTEM with additional spray attachments and accessories
oers the right tool for each work.
Accessories (not included in the delivery)
Name Order No.
HVLP handle extension
For easier coating of ceilings and horizontal objects. 2307 678
Container with cover 800 ml
Ensures that the paint does not dry out and the solvent does not
evaporate.
0413 909
