HV4901
Malfunction Cause Remedy
Paint in the
ventilating hose
•
Diaphragm soiled
•
Diaphragm defective
➞ Clean the diaphragm
➞ Replace the diaphragm
Device does not
function
•
Device overheated ➞ Unplug the power
plug, let the device
cool down approx. 30
minutes, do not bend
the hose, check the air
lter, do not cover the
intake slots
Poor covering
capacity on the
wall
•
Spray material is too cold
•
Highly absorbent surface or paint
with poor covering capacity
•
Distance too large
➞ The material you are
spraying should be at
room temperature
➞ Cross spray (Fig. 12)
➞ Closer to the object
25. Technical Data
Technical Data
Power source 230 V
~
, 50 Hz
Power consumption 760 W
Double insulation
Air hose length 3.5 m
Weight approx. 3.3 kg
