CChhaapptteerr 22 IInnssttaallllaattiioonn
22..11 IInnssttaallllaattiioonn
Risk of electrical shock. Only qualified service personnel (such as a licensed electrician) should perform the
electrical installation.
To prevent electrical shock or damage to the equipment, verify that the Eaton UPS is OFF before you remove
the entrance panel. The circuit breaker or disconnect switch must also be off at the AC input service panel.
Also, turn OFF the AC disconnect and bypass switches before you connect any wires to the bypass switch
terminal strip.
22..22 BByyppaassss PPoowweerr MMoodduullee DDiimmeennssiioonnss
Figure 1 shows the dimensions of the Bypass Power Module (BPM) in millimeters (inches).
Figure 1. BPM Dimensions (in millimeters)
0.0
0.0
0.0
130.1
(5.1)
603
(23.7)
663
(26.1)
440
(17.3)
