DIP Switch Settings
For complete DIP switch calibration AC
current tables of all Models, see the
following tables (Tables 3-2 thru 3-12).
DIP Switch Ampere Settings ES045
Table 3-2
DS1 DS2
POSITIONS
123 123 123 123 123 123 123 123
1 2 3 4 000 001 010 011 100 101 110 111
0 0 0 0 12.7 11.1 10.1 9.0 8.0 7.4 6.9 6.4
0 0 0 1 16.4 14.4 13.1 11.8 10.5 9.7 9.1 8.4
0 0 1 0 19.4 17.2 15.6 14.2 12.7 11.7 10.9 10.2
0 0 1 1 22.5 20.0 18.3 16.6 14.9 13.8 12.9 12.1
0 1 0 0 25.5 21.8 20.0 18.2 16.3 15.1 14.2 13.3
0 1 0 1 27.2 24.4 22.4 20.4 18.4 17.0 16.0 15.0
0 1 1 0 29.5 26.5 24.4 22.3 20.2 18.7 17.6 16.5
0 1 1 1 31.9 28.8 26.5 24.3 22.0 20.5 19.3 18.1
1 0 0 0 33.4 30.2 27.9 25.6 23.2 21.7 20.4 19.2
1 0 0 1 35.6 32.2 29.8 27.5 25.0 23.3 22.0 20.7
1 0 1 0 37.4 34.0 31.5 29.1 26.5 24.7 23.4 22.0
1 0 1 1 39.2 35.7 33.2 30.7 28.0 26.2 24.8 23.4
1 1 0 0 40.4 36.9 34.3 31.8 29.0 27.2 25.8 24.3
1 1 0 1 42.0 38.5 35.9 33.3 30.5 28.6 27.1 25.6
1 1 1 0 43.5 39.9 37.3 34.6 31.8 29.9 28.2 26.8
1 1 1 1 45.0 41.4 38.7 36.0 33.1 31.1 29.6 28.0
