Eaton Cutler-Hammer Easy-Start ES Series - Dip Switch Ampere Settings ES070; Dip Switch Ampere Settings ES120

Easy-Start ES Instruction Manual
Operation
SECTION 3
3-5
DIP Switch Settings
DIP Switch Ampere Settings ES070
Table 3-3
DIP Switch Ampere Settings ES120
Table 3-4
DS1 DS2
POSITIONS
123 123 123 123 123 123 123 123
1 2 3 4 000 001 010 011 100 101 110 111
0 0 0 0 19.7 17.3 15.6 14.1 12.5 11.5 10.7 9.9
0 0 0 1 25.5 22.4 20.4 18.4 16.4 15.1 14.1 13.1
0 0 1 0 30.2 26.8 24.3 22.0 19.7 18.2 17.0 15.9
0 0 1 1 35.1 31.2 28.5 25.8 23.2 21.4 20.1 18.8
0 1 0 0 38.1 34.0 31.1 28.3 25.4 23.5 22.1 20.6
0 1 0 1 42.4 37.9 34.8 31.8 28.6 26.5 24.9 23.3
0 1 1 0 45.9 41.2 37.9 34.7 31.4 29.1 27.4 25.7
0 1 1 1 49.6 44.8 41.2 37.8 34.2 31.9 30.1 28.2
1 0 0 0 52.0 47.0 43.4 39.9 36.1 33.7 31.8 29.9
1 0 0 1 55.3 50.2 46.4 42.7 38.8 36.2 34.2 32.2
1 0 1 0 58.1 52.8 49.0 45.2 41.2 38.5 36.4 34.2
1 0 1 1 61.0 55.6 51.6 47.7 43.6 40.8 38.7 36.4
1 1 0 0 62.8 57.3 53.4 49.4 45.1 42.3 40.1 37.8
1 1 0 1 65.4 59.9 55.8 51.8 47.4 44.5 42.2 39.8
1 1 1 0 67.7 62.1 58.0 53.9 49.4 46.4 44.1 41.6
1 1 1 1 70.0 64.4 60.2 56.1 51.5 48.4 46.1 43.5
DS1 DS2
POSITIONS
123 123 123 123 123 123 123 123
1 2 3 4 000 001 010 011 100 101 110 111
0 0 0 0 33.8 29.6 26.8 24.1 21.4 19.7 18.4 17.1
0 0 0 1 43.7 38.5 34.9 31.5 28.1 25.9 24.2 22.5
0 0 1 0 51.8 45.9 41.7 37.8 33.8 31.2 29.2 27.2
0 0 1 1 60.1 53.4 48.8 44.3 39.7 36.7 34.4 32.2
0 1 0 0 65.3 58.2 53.3 48.4 43.5 40.3 37.9 35.4
0 1 0 1 72.6 65.0 59.6 54.5 49.0 45.4 42.8 40.0
0 1 1 0 78.7 70.7 65.0 59.5 53.8 49.9 47.0 44.0
0 1 1 1 85.1 76.7 70.7 64.8 58.7 54.6 51.6 48.3
1 0 0 0 89.2 80.6 74.4 68.4 62.0 57.8 54.5 51.2
1 0 0 1 94.8 86.0 79.5 73.3 66.5 62.1 58.7 55.2
1 0 1 0 99.6 90.5 84.0 77.5 70.6 65.9 62.3 58.7
1 0 1 1 104.5 95.3 88.5 81.8 74.7 69.9 66.3 62.4
1 1 0 0 107.6 98.3 91.5 84.7 77.4 72.4 68.7 64.8
1 1 0 1 112.1 102.7 95.7 88.8 81.3 76.2 72.3 68.3
1 1 1 0 116.0 106.5 99.4 92.4 84.7 79.6 75.5 71.4
1 1 1 1 120.0 110.4 103.2 96.1 88.3 83.0 79.0 74.6
